前言

在以前我们在私有环境下创建 Kubernetes 集群时,我们需要准备一个硬件/软件的 负载均衡器 来创建多控制平面集群,更多的情况下我们会选择使用 HAProxy + Keepalived 来实现这个功能。一般情况下我们创建2个负载均衡器的虚拟机,然后分配一个 VIP,然后使用 VIP 为负载均衡器提供服务,通过 VIP 将流量重定向到后端的某个 Kubernetes 控制器平面节点上。
如下图所示:



接下来我们再来看看如果使用 kube-vip 的话会怎样呢?

可以看到,这样实现后使得架构变得更为的优雅,少了之前架构中 负载均衡 服务器的使用。


环境说明

  • 节点说明
IP地址操作系统内核版本
192.168.28.31 (k8s-master-01)CentOS Linux release 7.9.2009 (Core)3.10.0-1160.el7.x86_64
192.168.28.32 (k8s-master-02)CentOS Linux release 7.9.2009 (Core)3.10.0-1160.el7.x86_64
192.168.28.33 (k8s-master-03)CentOS Linux release 7.9.2009 (Core)3.10.0-1160.el7.x86_64
192.168.28.51 (k8s-node-01)CentOS Linux release 7.9.2009 (Core)3.10.0-1160.el7.x86_64
192.168.28.30 (kube-vip)
  • 软件说明
名称版本
kubernetes1.22.3

安装部署


1. 所有节点都要执行

  • 更改hostname
bash
  • 01
hostnamectl set-hostname k8s-master-01
  • 添加hosts记录
bash
  • 01
  • 02
  • 03
  • 04
  • 05
  • 06
cat <<EOF >> /etc/hosts 192.168.28.31 k8s-master-01 192.168.28.32 k8s-master-02 192.168.28.33 k8s-master-03 192.168.28.51 k8s-node-01 EOF
  • 脚本安装k8s环境
bash
  • 001
  • 002
  • 003
  • 004
  • 005
  • 006
  • 007
  • 008
  • 009
  • 010
  • 011
  • 012
  • 013
  • 014
  • 015
  • 016
  • 017
  • 018
  • 019
  • 020
  • 021
  • 022
  • 023
  • 024
  • 025
  • 026
  • 027
  • 028
  • 029
  • 030
  • 031
  • 032
  • 033
  • 034
  • 035
  • 036
  • 037
  • 038
  • 039
  • 040
  • 041
  • 042
  • 043
  • 044
  • 045
  • 046
  • 047
  • 048
  • 049
  • 050
  • 051
  • 052
  • 053
  • 054
  • 055
  • 056
  • 057
  • 058
  • 059
  • 060
  • 061
  • 062
  • 063
  • 064
  • 065
  • 066
  • 067
  • 068
  • 069
  • 070
  • 071
  • 072
  • 073
  • 074
  • 075
  • 076
  • 077
  • 078
  • 079
  • 080
  • 081
  • 082
  • 083
  • 084
  • 085
  • 086
  • 087
  • 088
  • 089
  • 090
  • 091
  • 092
  • 093
  • 094
  • 095
  • 096
  • 097
  • 098
  • 099
  • 100
  • 101
  • 102
  • 103
  • 104
  • 105
  • 106
  • 107
  • 108
  • 109
  • 110
  • 111
  • 112
  • 113
  • 114
  • 115
  • 116
  • 117
  • 118
  • 119
  • 120
  • 121
  • 122
  • 123
  • 124
  • 125
  • 126
  • 127
  • 128
#!/bin/bash # kubeadm安装k8s # ***需要设置所有主机的主机名*** # 安装所需的基本环境 # cat <<EOF >> /etc/hosts # 10.100.5.100 k8s-master-01 # 10.100.5.101 k8s-master-02 # 10.100.5.102 k8s-master-03 # 10.100.5.35 k8s-node-01 # 10.100.5.36 k8s-node-02 # 10.100.5.37 k8s-node-03 # 10.100.5.38 k8s-node-04 # 10.100.5.39 k8s-node-05 # 10.100.3.158 k8s-node-06 # EOF K8S_VERSION=1.22.3 CRICTL_VERSION=1.22.0 # https://github.com/kubernetes-sigs/cri-tools/releases/download/v1.22.0/crictl-v1.22.0-linux-amd64.tar.gz CRICTL_ADDR=http://nas.hardhtml.com:8800/linux/crictl-v${CRICTL_VERSION}-linux-amd64.tar.gz # 关闭swap sed -i 's/^[^#].*swap*/#&/g' /etc/fstab swapoff -a # 关闭防火墙和selinux systemctl disable firewalld && systemctl stop firewalld sed -i "s/^SELINUX=enforcing/SELINUX=disabled/g" /etc/selinux/config setenforce 0 # 清空规则 iptables -F # 安装nfs-utils yum install -y nfs-utils # 安装ntp服务 yum install -y ntp systemctl start ntpd && systemctl enable ntpd # 调整系统时区 systemctl restart rsyslog systemctl restart crond # 安装containerd # yum remove -y docker* yum install -y yum-utils device-mapper-persistent-data lvm2 yum-config-manager --add-repo http://mirrors.aliyun.com/docker-ce/linux/centos/docker-ce.repo # yum-config-manager --add-repo https://download.docker.com/linux/centos/docker-ce.repo yum install -y containerd.io-1.4.11 containerd config default > /etc/containerd/config.toml # 设置参数优化 sed -i "s#k8s.gcr.io#registry.cn-hangzhou.aliyuncs.com/google_containers#g" /etc/containerd/config.toml sed -i '/containerd.runtimes.runc.options/a\ \ \ \ \ \ \ \ \ \ \ \ SystemdCgroup = true' /etc/containerd/config.toml sed -i "s#https://registry-1.docker.io#https://registry.cn-hangzhou.aliyuncs.com#g" /etc/containerd/config.toml cat <<EOF > /etc/modules-load.d/containerd.conf overlay br_netfilter EOF modprobe overlay modprobe br_netfilter systemctl enable containerd && systemctl restart containerd # 安装crictl if [ -e '/usr/bin/crictl' ];then mv /usr/bin/crictl /tmp/ fi wget $CRICTL_ADDR -P /opt/ tar -zxvf /opt/crictl-v${CRICTL_VERSION}-linux-amd64.tar.gz -C /usr/bin/ cat << EOF > /etc/crictl.yaml runtime-endpoint: unix:///run/containerd/containerd.sock image-endpoint: unix:///run/containerd/containerd.sock timeout: 10 debug: false EOF crictl --version # 设置k8s内核参数 cat <<EOF > /etc/sysctl.d/k8s.conf net.bridge.bridge-nf-call-ip6tables = 1 net.bridge.bridge-nf-call-iptables = 1 net.ipv4.ip_forward = 1 EOF # 加载内核参数 modprobe br_netfilter sysctl --system sysctl -p /etc/sysctl.d/k8s.conf # kube-proxy开启ipvs的前置条件 cat > /etc/sysconfig/modules/ipvs.modules <<EOF #!/bin/bash modprobe -- ip_vs modprobe -- ip_vs_rr modprobe -- ip_vs_wrr modprobe -- ip_vs_sh modprobe -- nf_conntrack_ipv4 EOF # 脚本创建了的/etc/sysconfig/modules/ipvs.modules文件,保证在节点重启后能自动加载所需模块。 使用lsmod | grep -e ip_vs -e nf_conntrack_ipv4命令查看是否已经正确加载所需的内核模块 chmod 755 /etc/sysconfig/modules/ipvs.modules && bash /etc/sysconfig/modules/ipvs.modules && lsmod | grep -e ip_vs -e nf_conntrack_ipv4 yum install ipvsadm ipset -y # 添加阿里云kubernetes的yum源 cat <<EOF > /etc/yum.repos.d/kubernetes.repo [kubernetes] name=Kubernetes baseurl=http://mirrors.aliyun.com/kubernetes/yum/repos/kubernetes-el7-x86_64 enabled=1 gpgcheck=0 repo_gpgcheck=0 gpgkey=http://mirrors.aliyun.com/kubernetes/yum/doc/yum-key.gpg http://mirrors.aliyun.com/kubernetes/yum/doc/rpm-package-key.gpg EOF # 安装kubelet,kubeadm,kubectl yum install -y kubelet-${K8S_VERSION} kubeadm-${K8S_VERSION} kubectl-${K8S_VERSION} && systemctl enable kubelet

参考文献
https://www.treesir.pub/post/kube-vip-deploy-ha-k8s-cluster/
https://kubernetes.io/docs/setup/production-environment/container-runtimes/
